Component Locations

Visual reference guide for all EDC components, storage locations, and edition-specific differences.

Overview​

This page provides a comprehensive reference for locating all components within your HiveRadar EDC. Use this guide during setup, maintenance, or when looking for specific items.

What's Covered:

  • Front and rear panel components
  • Internal component layout (2 shelves)
  • Storage locations in lids
  • Edition-specific differences (NUC vs HR-01)

Front Panel Components​

When front lid is removed, you'll see:

NUC PRO Edition

alt text

HR-01-2 Edition

alt text

Compute Drawer​

Location: Center, backlit drawer with server nodes

📦 NUC Edition:

  • 3× Intel NUC Pro nodes (side by side)
  • Labeled 1, 2, 3
  • Individual bays with rubber dampening
  • Access via pull handle

🔶 HR-01-2 Edition:

  • 2× HR-01 Edge Server nodes
  • Labeled 1, 2
  • Full-depth server chassis
  • Access via pull handle

🔷 HR-01-4 Edition:

  • 4× HR-01 Edge Server nodes
  • Labeled 1, 2, 3, 4
  • High-density configuration

Accessing Drawers: All drawers (compute and storage) use twist-lock mechanisms on left and right sides. Twist either upward or downward ~90° to unlock. For complete drawer operation instructions, see Storage Drawers.

Switch​

Location: Below compute drawer

All Editions:

  • EnGenius ECS2510FP switch (8-port 2.5GbE) or ECS5512FP (10-port 10GbE; upgraded)
  • Front-facing RJ45 ports (Ports 1-8)
  • Status LEDs visible
  • Management port accessible

Rear Panel Components​

When rear lid is removed, you'll see:

NUC PRO Edition

alt text

HR-01-2 Edition

alt text

Full-Depth Storage Drawer​

Location: Top drawer, full-depth

📦 NUC Edition:

  • Carbon fiber telescopic pole
  • Accessory pouch
  • T-bar Bracket
  • Gateway and associated antennas (if purchased)

🔶 🔷 HR-01 Editions:

  • Carbon fiber telescopic pole
  • Accessory pouch
  • T-bar Bracket
  • Gateway and associated antennas (if purchased)

Note: The HR-01-2 mode with 2 HR-01 Edge servers supports a configuration, where instead of the Mako 5600 Security Gateway or other device storage, you can accomodate storage for StarLink Mini instead by moving the clamps to accomodate it.

Rear Storage Drawer​

Location: Above PDU, short-depth drawer

📦 NUC Edition:

  • Starlink Mini dedicated storage space
  • Power cable and adaptor for StarLink Mini
  • Alternatively can be repurposed for other tools

🔶 HR-01-2 Edition:

  • Too short for Starlink Mini
  • Power cables and adapters
  • Spare hardware
  • General accessories

Power Distribution Unit (PDU)​

Location: Below the short depth drawer

All Editions:

  • EnGenius ECP106 (North America) or ECP106-INT (International)
  • 6× power outlets
  • LCD display showing power consumption
  • Network port for monitoring
  • Physical power switches per outlet

What's Next?​

After familiarizing yourself with component locations:

📦 NUC Edition Users: 👉 Continue to Part 3: Hardware Installation to install compute nodes (if your EDC comes without pre-installed nodes)

🔶 🔷 HR-01 Edition Users: 👉 Skip to Part 4: Software Configuration (your nodes are pre-installed)
